Aerogel Insulation Mat Sheet Pad Board Blanket
High Performance | Low Cost | Long Lasting
Wedge WAG 650 are low density, low thickness, flexible commercial grade Aerogel Blanket having extremely high performance in pipe insulation in both industrial and buildings applications. The AG06 650 aerogel insulation blankets are made of high quality silica aerogel and of glass fiber needled blanket.
​
Aerogel is porous, gel-derived ultralight material in which the liquid component of the gel is replaced by a gas without significant collapse of the gel structure. The result is a solid structure with extremely low thermal conductivity and extremely low density. Wedge is largest oem manufacturer of Aerogel Insulation systems in India made in form of Blanket, Panel, Granules, Monolith, and Board. The SiO2 aerogel composite is made of non-crystal silica gel and substrate, it was dried in supercritical fluid CO2. It can effectively reduce the high brittleness of aerogel and enhance the structure between aerogel and substrate.
It is widely used in a variety of fields, such as construction, refineries, automotive, batteries insulation, pipelines, precision instrument etc. The non-organic structures of these products, which are non-combustible and can bear heat up to 1400 Degree C. Aerogel exhibit excellent heat endurance and thermal insulation properties, which boosts their demand.
​


Features and Benefits
-
Lightweight, thin, custom made & very flexible
-
Water 💦 Repellent 100% Hydrophobic
-
Thinnest possible insulation after vacuum.
-
Delivers better performance with lower weight
-
Aerogels lower thermal conductivity (0.015 W/m. K)
-
The conduction through aerogels is made minimal.
-
Better insulation than still air
-
Better insulation than Rockwool, EPS, PUF, PIR
-
Superior Thermal Performance
-
Up to five times better high-thermal performance
-
Less Time and Labour cost to Install
-
Reusable lower maintenance cost
-
Shipping and Warehousing Savings
-
A1 Fireproof and Waterproof, 99% Hydrophobicity
-
Environmentally Safe, Longer Service Life
-
Sound Insulation and Shock Absorption
-
Wide working temperature range -50 to 650 Degree C.

Applications
-
Hot Water / Gas / Oil Pipeline
-
High heat Steam Pipeline
-
EV Lithium Ion Battery Insulation
-
Petrochemical industry & power generation
-
Back-up insulation in refractory lined pipes
-
Exhaust systems
-
Filler material for mattresses, cassettes, heat shields, expansion joints
-
Prefabricated pipe with insulation
-
Tanks, vessels and other equipment
-
Pipe line insulation in Petrochemical plants
-
Automobile, high-speed, train, and subway
-
Building and Construction
-
PFP (Passive Fire Protection)


Insulation U R Value Heat Loss Calculator
Right Insulation Materials Selection to get most feasible commercial solution. Achieving right combination of Insualtion materials and thickness is most complex decision to achieve lowest heat loss with minimum insulation thickness at various applications and temperatures. Wedge India helps its client to select right combination of Insulation material for various applications based on R Value heat loss calculator software, u p k calculations to find right insulation thickness, achieve target cold face temperature, and minimise heat losses at very low price. We also make energy audits as per requests from our customers. R value calculator delivers best insulation thickness r30 r38 r19 r49 r21 r60 for home and buildings to save cost at high efficiency.
​
Get Thermal Calculation, Insulation Thickness, Heat Loss
​
Benefits of Heat Loss Calculator
-
Get right Thickness of Insulation.
-
Find right Insulation Materials Selection.
-
Get lowest cost combination of Insulation System.
-
Get better heat loss reduction decision.
-
Clear view of Energy Saving potential and Energy Audits.
-
Low cost and optimum Furnace Design.
-
Best Energy cost reduction possibilities.
Technical Specification of Wedge Aerogel
Quality : WAG650-3
Thickness, mm : 3 - 20 mm
Length, m : 38
Width, mm : 1500
Colour : White
Density kg/m3 : 220
Classification Temperature ºC : -50 to 650
Shor term Temperature Resistance more than 5 minutes ºC : 1200
Compression Strength at 10% KPa : 100
Non combustibility test
Classification, Fire Proofing : A1
Tensile Strength KPa 1400
Thermal conductivity at 25°C W/m.K 0.018
Thermal conductivity at 200°C W/m.K 0.028
Thermal conductivity at 300°C W/m.K 0.036
Thermal conductivity at 400°C W/m.K 0.047
Thermal conductivity at 500°C W/m.K 0.068
Hydrophobicity % 99
Coverings :Aluminium Foil, E-Glass Cloth, Ceramic Paper, Mica, Millboard, Steel
​
For more details Download Technical Data Sheet


Aerogel Comparison with other insulation
In comparison with other insulation materials such as Rockwool it gives 4 to 5 times higher performance.


50% Heat Loss Reduction
30% Temperature Reduction



What are end Uses of Aerogel insulation?
The main applications are in oil & gas, construction, transportation, performance coating, day-lightning, and LVHS. The blanket form is the largest segment of the aerogel market. It was the first form of commercial aerogel for various applications. The blanket material has a clear value proposition, as it is super insulating and two to three times better than particle material in terms of thermal properties. Blanket materials are used for a broad range of applications, such as oil & gas, construction, automotive, and marine and aerospace, as these can be cut and modified as per specific requirements due to their flexible physical structure.
-
Pipeline Insulation
-
Industrial cryogenics thermal barriers
-
Lithium ion batteries insulation in EVs
-
Interior insulation solutions for building retrofit
-
Thin facade insulation for the renovation
-
Building roof Insulation
-
Door Insulation
-
Fire Safety clothing and Apparel




What are key market trends in Aerogel Insulation Industry?
Silica aerogel is one of the most common types of aerogel, and the most extensively used one. Currently, silica aerogel is commercially obtained using silica gel, or by using a modified process.
Upon exposure to an open environment, the silica content in silica aerogel solidifies into the three-dimensional structure and makes up about 3% of the volume. The remaining 97% of the volume is completely composed of air in extremely small nano porous. Hence, due to the presence of only 3% of solid content, conduction through the silica aerogel is extremely low. Silica aerogels also have a high optical transmission of about 99% and a low refractive index.​
Silica aerogel has low density, low thermal conductivity, low sound speed, low refractive index, and high transparency, which makes it suitable to be used for super-capacitors, water deionisers, sensors for gas detection, pollution filters, dielectric integrated circuits, absorbents, catalysis, matching layers for acoustical transducers, sound insulation, kinetic energy absorbers, sound insulation, impact protection, nuclear particle detectors, and many more.​
The use of silica aerogel is gaining significant attention from the aerospace industry in recent years, due to its exceptional insulation properties and lightweight nature.
In the oil and gas industry, it is widely used in insulation packs for oil and gas subsea pipelines. In the construction industry, its application can be found in architectural panels, glass units, and tensile roofing systems, among other applications.​
